24-Hour Self-Service Water Supply
1200 GPD Community Water Vending Machine
This system is specifically designed for community water supply points and outdoor self-service water supply schemes, with a daily treatment capacity of 1,200 GPD. It integrates reverse osmosis purification, UV and ozone disinfection, water storage and configurable payment functions. The final configuration will be selected based on the quality of the incoming water, climate, voltage and local payment requirements.
1200 GPD
24-hour unmanned operation
RO + UV purification
Room-temperature + cold water
Configurable payment methods
Water storage
220L
Rated Production Capacity:
1,200 GPD (approximately 4,540 L/day)
Insulation system
Three-in-one insulation (-40℃ low temperature protection)
Water quality testing
Real-time data monitoring + IoT control
INTEGRATED SYSTEM
Purify, Store and Vend in One Machine
The product combines water treatment and customer-facing vending functions in one outdoor self-service unit.
01 · PURIFY
RO + UV Water Treatment
Integrated PP, UDF, CTO, PP, RO, T33 and UV treatment before storage and dispensing.
02 · STORE
Water Storage
Built-in independent water tank storage meets customers’ needs for on-demand water use.
03 · VEND
Unmanned Dispensing
Configured payment functions allow customers to obtain water without a permanently staffed sales counter.
CURRENT PRODUCT DATA
Water Vending Machine Specifications
Product Name
Community Water Vending Machine
Rated Production Capacity
1200 GPD (approximately enough for 300 people/day)
Storage Tank Capacity
220L
Water Tank Material
Stainless steel / PVC
Main Unit Material
Galvanized sheet / Custom
Insulation System
Supports operation at -40℃
Treatment Process
PP + UDF + CTO + PP + RO + T33 + UV
Voltage
110V / 220V / 380V / Custom
Feed-Water Source
Tap Water
Inlet Water Pressure
0.2-0.4 Mpa
Payment Methods
Coins, cards, QR codes
Warranty
1 year
Note: The system’s processing capacity can be customized to your needs [e.g., 800-1600 GPD], as well as the number of filling ports [1-3pcs].
PURIFICATION PROCESS
Integrated Treatment Before Dispensing
10 core filtration stages + 2 sterilization processes ensure water safety.
Feed Water
→
PP
→
UDF
→
CTO
→
PP
→
RO
→
T33
→
Ozone+UV
→
Storage
→
Dispensing
CUSTOMER EXPERIENCE
Simple Self-Service Water Purchase
01
Bring Container
Place a suitable container at the dispensing position.
02
Choose Payment
Use the payment method configured for the local project.
03
Dispense Water
Start dispensing treated room-temperature or cold water.
04
24-Hour Access
The vending concept supports unmanned customer access.
Payment Methods
Configure the Local Vending Experience
The exact payment system should be confirmed according to machine version and the destination market.
Coin Acceptor
Configured for supported local currencies
Prepaid/NFC Card
Optional according to machine version
QR Code
Requires integration with a compatible local payment provider
WATER VENDING BUSINESS MODEL
Estimate Local Water-Sales Revenue
Enter the corresponding traffic and sales price to get an intuitive sales forecast.
This estimates gross sales only. A real business plan should also include source-water cost, electricity, filters and RO membrane, rent, payment fees, cleaning, maintenance, taxes and machine investment.
Gross Water-Sales Estimate
Updates automatically from the values on the left.
APPLICATIONS
Where This Water Vending Machine Fits
Community Water Points
Self-service purified-water access for residential areas and community projects.
Outdoor Water Supply
Unattended water dispensing where a staffed retail counter is not practical.
Local Water-Sales Projects
Projects combining treatment, storage, payment and vending in one unit.
WHY AQUACLARION
Water-Treatment Expertise Behind the Vending System
- Integrated RO water treatment and vending-machine configuration
- Supports multiple voltages, such as 220V/380V/110V Etc…
- Supports operation at -40℃
- Factory testing before packing and shipment
- Online and video technical support
- Customization according to project requirements
BEFORE QUOTATION
Tell Us Your Local Project Requirements
Country, voltage, feed-water source, expected daily sales, whether cold water is required, preferred payment method, vending windows and cabinet / branding requirements.
Water Vending Machine FAQ
Yes. The machine is designed for 24-hour self-service operation. Customers can select the configured payment method and dispense water without a permanently staffed counter. Regular refilling checks, cleaning and preventive maintenance are still required.
Yes. A typical configuration includes sediment filtration, activated-carbon filtration, reverse osmosis, post-carbon polishing, ozone disinfection and UV sterilization. The final treatment process should be confirmed according to the feed-water analysis and required drinking-water standard.
The rated capacity is approximately 1,200 US gallons per day, equivalent to about 4,540 liters per day. This represents approximately 189 liters per hour when operated continuously for 24 hours. Actual output depends on feed-water temperature, pressure, TDS, membrane condition and operating hours.
The system supports coin payment, QR code mobile payment, and NFC card payment.
Please provide the destination country, voltage and frequency, feed-water source, expected daily water demand, required dispensing temperature, preferred payment method, local climate, cabinet or branding requirements and installation location. A water-analysis report is strongly recommended when available.
